Window Dryer Vent Specifications
|Product Name||Window Dryer Vent|
|(760999896021) (709870687013) (709870687006)|
|SKU||(WDV-14) (WDV-18) (WDV-24)|
|(2lbs) (3lbs) (4lbs)|
|Shipping Weight||(4lbs) (5lbs) (6lbs)|
|Dimensions||Panel Height 8" inch
Panel Width 1-1/8" inch
Panel Length 14"-18" inch, 18"-24" inch, 24"-36" inch (3 sizes)
Hood Height 6" inch
Hood Width 5" inch
Hood Sticks Out 4-1/4" inch
Duct Diameter 4" inch round duct outlet (standard dryer vent)
|Material||24 Gauge Galvanized Steel
Aluminum Spring Loaded Back-Draft Damper
For more information go to Window Dryer Vent
What do you think? We want to know so please leave us a comment below.
Thanks In Advance
Once the necessary supplies have been acquired, the first step in this process will be to use the tape measure to find out what the height and width of the window in question is. After this is done, lay the acrylic sheet on a flat surface and trace out the exact measurements of the window onto the sheet.
If you're going to be using the window dryer vent as a permanent solution and you live in harsh climates, we suggest you insulate it. In this article, we show how to insulate the window vent with rigid foam board insulation which is our preferred method, then describe insulation effectiveness.
