Rectangular Wall Vent

  • When venting through a wall is the best option a quality wall vent should be considered; the rectangular wall vent by Vent Works was designed with a spring loaded back draft damper and weather seal to prevent drafting from outdoors, we also included a ¼” inch steel mesh screen. For easy installation there are mounting holes of the flange. These heavy gauge vents are not available at your local home improvement or general hardware stores. There are 2 different material options; galvanized (26 gauge) and aluminum (high grade). There are 3 size options; the standard 10" inch, 12" inch, and 14" inch. Our rectangular wall vents are most commonly used in kitchen exhaust applications.

    To Install: to allow space for installation add an extra 1/8” inch to the height and width, cut the hole in the side wall and install, be sure to seal it.

  • NOT FOR USE AS FRESH AIR INTAKE

  • Rectangular Wall Vent Specifications

    • Duct Width: 10", 12", 14" inch
    • Duct Height: 3-1/4" inch
    • Duct Length: 4-1/2" inch
    • Flange Height: 5-5/8" inch
    • Flange Width: 12-3/4" inch, 14-9/16" inch, 16-9/16" inch
    • Hood Sticks Out: 5" inch
    • Hood Width: 11" inch, 12-7/8" inch, 15-7/8" inch
    • Hood Height: 5" inch
    • Material: 26 gauge galvanized steel or high grade aluminum.
    • Screen: 1/4" inch steel mesh screen.
    • Damper: Spring-loaded backdraft damper with foam weather seal.
    • Made In USA
  • Can I use this with a kitchen exhaust fan? (range hood)

    Yes; that is the most common use for rectangular wall vents.

    Can the screen be removed?

    Yes; these wall vents have a removable 1/4" inch steel mesh screen.

    Can the wall vent be painted to match my house color?

    Yes; first prep by wiping down with a solvent like lacquer thinner or paint thinner to remove all oil residue so primer will adhere properly. Then use an epoxy or etching primer as a base. Then paint it with the color matched paint.
