DIY Hobby Spray Booth Kit

DIY Hobby Spray Booth Kit

Regular price $107.99
Regular price $125.97 Sale price $107.99
Sale Sold Out
Shipping calculated at checkout.
View full details

The DIY Hobby Spray Booth Kit

Easily Build A Spary Booth At Home

This DIY Hobby Spray Booth Kit includes all 3 of the components we produce for spray booths.

Fan Mount Panel which provides an easy way to mount a Dayton Blower 6FHX9 onto a DIY Hobby Spray Booth.

Filter Rack designed to hold a 12x24x1 inch standard furnace filters.

Square to Round Fan Adapter to exhaust the Dayton Blower 6FHX9. This adapter transitions from the odd-sized square exhaust outlet on the blower to a standard 4 inch circular duct.

Build your own spray booth and do it right the first time! Read the article to see how we did it.

DIY Hobby Spray Booth Assembly Image

Assembly Instructions & Material Cut List

View Now

Collapsible content

Specs

Filter Rack

  • 24 Gauge Galvanized Steel
  • Accepts 12x24x1 Inch Standard Replacement Furnace Filter
  • Hardware Included (8 QTY  # 6 x ½ Inch Nuts & Bolts)
  • Made in USA

Fan/Blower Mount Panel

  • 24 Gauge Galvanized Steel
  • Hardware Included
  • Foam Gasket Included

Square To Round Adapter

  • 24 and 28 Gauge Galvanized Steel
  • 4 Inch Round Duct
  • Hardware Included
  • Foam Gasket Included

Features

100% SATISFACTION GUARANTEED

Our spray booth parts easily withstand the rigors of time, ensuring peak performance and efficiency that endures. With every component sourced domestically, we stand firmly behind the quality of our hobby spray booth parts. Your satisfaction is our commitment – backed by a 100% money-back guarantee. Trust in the resilience of America's finest, and rest assured that you're making a wise investment in one of the best spray booth solutions available.

FAQs

Do I have to use special filters?

No, Actually the cheap standard furnace filters work best, if you use an expensive allergen filter e.g. filtrate furnace filter it will restrict flow and could cause inadequate ventilation.

Does the filter rack require assembly?

Yes, it comes as four pieces of steel that must be bolted together. It's only 8 little nuts and bolts so assembly takes about 1 minute. All you will need is a Phillips head screwdriver.

Do I have to change the filter?

Yes, periodically filters should be replaced and ducts should be inspected for obstructions. This will ensure proper air flow which will reduce the risk of vapor buildup.

Do I have to use a specific fan/blower?

Yes, this panel may work with other similar blowers but it was designed specifically for use with the Dayton Blower model 1TDR3. Learn more about this blower: Dayton Blower 1TDR3

Does the fan mount panel require assembly?

No, it comes as one piece with hardware and foam seal included.  Of course you still have to mount the blower yourself. See video for more info:Mounting the Dayton Blower 1TDR3 Mount Panel

Where should I use the foam seal?

Everywhere, any hole, gap or spot where the panel touches the blower and is not fully sealed. See video for more info: Mounting the Dayton Blower 1TDR3an Mount Panel

Mounting the Dayton Blower 1TDR3 to the Fan Mount Panel

Installing the Square to Round Fan Adapter

Installing the Filter Rack
